GT-630F

5-axis Machining Center

GT-630F

Gantry type structure, moving axes driven at the center of gravity, dynamic capabilities greatly improved

5-axis simultaneous machining can complete complex processes in one-sitting

High rigidity structure with closed design

Gantry type movement, 3-axis feed rate will not affected by workpiece’s weight

Adopts oil air lubrication spindle, provides low heat and reach long lifetime feature

5-axis trunnion table is driven by roller gear cam motor, allowing for zero backlash, low abrasion, high positioning accuracy and long endurance




Download

Specification

Item GT-630F
Table size (L×W) Ø630 mm
Max. loading capacity 600 kg
X/Y/Z axis travel 760/820/560 mm
A/C axis travel +30°~-120°/±360° deg
X/Y/Z axis rapid traverse 48/48/48 m/min
A/C axis rapid traverse 25/25 rpm
Spindle taper 7/24 Taper No.40
Spindle speed 15000 (20000) (24000) rpm
Spindle motor 40/40 (40/30) (42/35) kW
Tool Capacity 32 (40) (64) (80) pc
