Home > Products > Machine Tool > Horizontal CNC Lathe > 10"~12" > TE-2500BHome > Products > Machine Tool > Horizontal CNC Lathe > 10"~12" > TE-2500BTE series is a substitute CNC lathe for TNL series in Tongtai. In this new series, the performances of structure rigidity and machining efficiency are improved than the prior ones
TE series equips a turret and two movement axes
Standard equipped with 8 tools servo turret, regard to the machining requirements, power turret is selectable and the maximum tool capacity is 16 tools
Sub-spindle is optional for allowing machine to complete both sides machining of parts in one time
| Specification | TE-2500B |
| Chuck size | 10" (12") inch |
| Bar capacity | Ø64/Ø74 mm |
| X/Z/B axis travel | 230/600/630 mm |
| X/Z/B axis rapid traverse | 30/30/30 m/min |
| Spindle nose | A2-8 |
| Spindle speed | 3,500 (2,500) rpm |
| Spindle motor | 18.5/15/11 kW |
| Tool capacity | 8/12(BMT65) pcs |
| Sub-spindle nose | A2-5 |
| Sub-spindle speed | 5,000 rpm |
| Sub-spindle motor | 7.5/5.5 kW |
| Sub-spindle chuck size | 6" inch |
