Structure is designed with finite element analysis, enhancing dynamic rigidity and stability
High efficiency turning capability and C-axis design that satisfied the machining demand of milling and turning
Servo driven turret allows for quick tool changing, reducing non-cutting time
Excellent cost performance value
| Specification | TC-1500[M] | |
| Chuck O.D. | 6" inch | |
| Bar capacity | Ø44 mm | |
| X/Z axis travel | 170[200]/400 mm | |
| X/Z axis rapid traverse | 30/30 m/min | |
| Spindle nose | A2-5 | |
| Spindle speed | 4800 rpm | |
| Spindle motor | 12/9/7.5 kW | |
| Tool capacity | 12 (8) [VDI-40:12] pc | |
