Highly dynamic rigidity structural design
Adopt oil air lubrication spindle, provides low heat and reach long lifetime features
Equipped with high speed, high precision control functions
BBT-40 dual contact tool holder system
Suitable for tooling industry
Specification | VC-711 |
Table size(LxW) | 1200x710 mm |
Max. loading capacity | 1000 kg |
X/Y/Z axis travel | 1100/710/710 mm |
X/Y/Z axis rapid traverse | 24/24/24 m/min |
Spindle taper | 7/24 Taper No.40 |
Spindle speed | 12000 (10000) (15000) (20000) rpm |
Spindle motor | 11/7.5 (15/11/7.5) (15/11) (18.5/15/11) (15/7.5) (18.5/11/7.5) (40/30) kW |
Tool capacity | 24 (30) pc |
VC-711
